High Precision Metal Products of Metal 120W Nanosecond Laser Welding Machine

Basic Info.

Model NO.	HY-WM03
Power Regulation	10-100%
Power Instability	<1.5%
Power Requirement	220V/50Hz&60Hz
Product Name	Nanosecond Laser Welding Machine
Overall Power Comsumption	<=500 W/600W
Application Material	Stainless Steel, Carbon Steel Aluminum
Laser Wavelength	1024nm
Cooling Method	Air Cooling
Laser Frenquency	1-2000Hz
Max. Power	60W/70W/120W
Laser Source	Jpt
Transport Package	Plywood Box
Specification	CE FDA
Trademark	HAIYI Laser
Origin	Jiangsu/China
HS Code	8515809090
Production Capacity	1000sets/Year

Product Description

Nanosecond Laser Welding Machine
1.PRODUCT DESCRIPTION :

Nanosecond fiber laser is used as the light source, with adjustable pulse width and high repetition rate. Spot welding with high speed galvanometer, high efficiency. The machine is free of any consumables and does not need maintenance.
2. APPLICATION :
The nanosecond Laser Welding Machine is widely used in the precise spot welding of 3C shrapnel, new energy, medical equipment, etc. other industries.

3.SPECIFICATION :

Model	HY-WM03 60W/70W/120W
Laser Power	60W/70W/120W
Laser Wavelength	1064nm
Laser Frenquency	1-2000HZ
Adjustable pulse width range	[email protected],60Khz
Cooling Method	Air Cooling
Working Area	X, Y Z Axis ( Option)
Monitor System	CCD or Microsope
Power Instability	<1.5%
Feeding Wires' Dimenson	2-250ns
Power requirement	220V/ 50&60HZ
Overall Power Consumption	<500W/600W
The Overall Size(LWH)	11009001000mm
Gross Weight	180KG

4.Advangtages :
1. Spiral welding, adjustable weld spot size, excellent welding strength. 2. Very stable welding of different materials. 3. Stable power, beautiful weld spots. 4. Efficient, stable, maintenance free, 24-hour uninterrupted operation.5. Long lifespan 100000hours, free of maintance
5. OUR SERVICE :
1. 1 year Guarantee for the whole machine.
2. 12 months Guarantee and free spare parts supply during this period.
3. 24 hours on line service
4. 3-7 days lead time
5. We will provide the Instruction Book, Operational manual and Training Video
6. Provide technical support for the whole lifetime on line
7. TT/Ali Trade Assurance payment
8. Shipping By air, DHL, Sea.
6.ABOUT US :

High Precision Metal Products of Metal 120W Nanosecond Laser Welding Machine

7.FAQ:
Q1. How to select the suitable machine?
Tell us your material, detail requirements by words, pictures or video.
We will recommend you the suitable model with the reasonable price.
Q2. How about the lead time?
For the standard machine, the delivery time is 3-7 days after the payment.
For the non-standard machine, the delivery time is 7-15 days after the payment.
Q3. How to install and use it?
We have the instruction Book, Operational manual and Training Video inside the machine.
We also can provide the training on line by free.
Q4. How to do it if we meet the issue during the operation?
You can send the wrong information to us by mail, we can help us solve it by mail.
phone, or video communication.
Q5. If we want to learn how to operate the machine, Can you provide it?
Yes, we can. We can provide the on line training by video. We also provide free training
course in our company.
Q6. Do you provide the onsite service if we needed?
Yes. We can provide the onsite service if you needed. But need the customer pay for the transport, hotel, food and 60USD/day.
